Keyword:	Vibratory Rammer, Hydraulic Compactor Plate	Application:	Urban Infrastructure Service Field
Brand:	P.A Tech	Type:	JXZ300/JXZ600/JXZ800/JXZ1000
OEM:	Available	After-sales Service:	Field Installation, Commissioning And Training, Field Installation
Video Outgoing-installation:	Available	Machinery Test Report:	Available
Warranty:	6 Months	Suitable For Excavator:	4-9ton...23-30ton
Weight:	400kg-1100kg	Bottom MeasurementD:	900x550x25mm...1350x900x30mm
Width:	550-900mm
High Light:	100l/Min Hydraulic Compactor Plate  ,   30 Tons Hydraulic Compactor Plate

---

Mounted Vibrator Compactor, Hydraulic Plate Compactor Used for dam and building foundation

Description of Hydraulic Compactor Plate, Vibratory Rammer
Rammer is also known as hydraulic vibration rammer. At present, the rammer can be divided into 5 levels according to the tonnage of supporting excavators: 02 (3-5 tons), 04 (5-8 tons), 06 (11-16 tons), 08 (17-23 tons) and 10 (23-30 tons). With simple structure, convenient operation and maintenance.

Application of Hydraulic Compactor Plate, Vibratory Rammer
1- Our Hydraulic Plate Compactor can be used to complete the treatment of plane compaction, slope compaction, step compaction.
2- It also called Vibrating Plate Compactor, can also be used for ditch pit compaction and other complex foundation compaction.
3- Our hydraulic vibrating plate mainly used for tamping slope, dam and building foundation engineering.

Parameters of Hydraulic Compactor Plate, Vibratory Rammer

Model	Unit	JXZ 300	JXZ600	JXZ 600	JXZ 1000
Impulse force	Ton	4	6.5	15	15
Vibration frequency	rpm	2000	2000	2000	2000
Oil flow	l/min	45-75	85-105	120-170	120-170
Operating pressure	kg/cm2	100-130	100-130	150-200	150-200
Weight	kg	400	750	1000	1100
Bottom measurement	(LXWXT)mm	900x550x25	1160x700x28	1350x900x30	1350x900x30
Height	mm	760	920	1060	1100
Width	mm	550	700	900	900
Suitable excavator	Ton	4-9	11-16	17-23	23-30



Our Service:

The warranty for our excavator attachments is six months. And, clients could enjoy our on-line consultation and answering service. All our excavator attachments could be customized, OEM is available. As a manufacturer who have strong strong capacity, we usually could arrange delivery for our excavator attachments within 15 days ( delivery can be within one week for cargo that have stock).

If you have any question or want to know more about our excavator attachments,please feel free to send aninquiry to us!We will do the best to help you!
