| Keyword: | Screener Crusher Bucket, Excavator Bucket | Application: | Construction, Demolition And Mining Services |
|---|---|---|---|
| Brand: | P.A Tech | Type: | JX-PE08/JX-PE10/JX-PE14 |
| OEM: | Available | After-sales Service: | Field Installation, Commissioning And Training, Field Installation |
| Video Outgoing-installation: | Available | Machinery Test Report: | Available |
| Warranty: | 6 Months | Suitable For Excavator: | 20-50T |
| Width: | 950/1050/1350mm | Min. Oil Quantity: | 170/190/220 L/min |
| Under Loaded Weight: | 3.0/3.5/4.9T | ||
| High Light: |
0.7m2 rock screening bucket,L1984mm rock screening bucket |
||
Screener Crusher Bucket, Bucket Crusher For Excavator, Used For Construction Sites
Description of Excavator Screener Crusher Bucket
The Crusher Bucket adopts advanced hydraulic technology. It uses the motor to rotate the jaw plate to squeeze the concrete, stones, etc., so that the scraps that meet the set requirements are spit out from the discharge port. The steel bars smaller than the discharge port can also be simultaneously The discharge port is discharged.
Bucket capacity : From 0.7 m3 to 1.1 m3. We adopt Sweden-made HARDOX steel as material Advanced digital control flame (plasma) cutting machinery.
Application of Excavator Screener Crusher Bucket
1- Excavator Crusher Bucket can be used for city garbage demolition
2- Our Excavator Crusher Bucket also can be used for bricks, concrete, stones crush job.
3- People use Excavator Crusher Bucket to do waste utilization work, which could save energy while protecting the environment.
4- Our Excavator Crusher Bucket are widely used in construction work, for example: in construction site, stone factories, etc.
Parameters of Excavator Screener Crusher Bucket
| Processing Capacity | Unit | CB-08A | CB-10A | CB-14A |
| Discharge Size m³/h | 140mm | 50 | ||
| 130mm | 34 | 41 | 47 | |
| 120mm | 31 | 36.5 | 44 | |
| 110mm | 29 | 34 | 41 | |
| 100mm | 27 | 32 | 38 | |
| 90mm | 25 | 29 | 36 | |
| 80mm | 22 | 27 | 33 | |
| 70mm | 20 | 25 | 30 | |
| 60mm | 18 | 20 | 27 | |
| 50mm | 16 | 20 | 24.5 | |
| 40mm | 15 | 17.8 | 22 | |
| 30mm | 13 | 15 | 19 | |
| 20mm | 11 | 13 | 15 | |
| Excavator | ton | >20 | >25 | >32 |
| Model | Unit | JX-PE08 | JX-PE10 | JX-PE14 |
| Underloaded Weight | ton | 3 | 3.5 | 4.9 |
| Height | mm | 1525 | 1663 | 1663 |
| Width | mm | 950 | 1050 | 1350 |
| Length | mm | 1984 | 2175 | 2175 |
| Volume +/-20% | ㎡ | 0.7 | 0.9 | 1.1 |
| Minimum Oil | l/min | 170 | 190 | 220 |
| System Max. Pressure | bar | 260 | 260 | 260 |
| Bucket size | Unit | JX-PE08 | JX-PE10 | JX-PE14 |
| Width | mm | 840 | 900 | 1190 |
| Height | mm | 400 | 460 | 460 |
| Jaw Size | Unit | 840 | 900 | 1190 |
| Feed | 250 | 300 | 300 | |
| Discharge | Max. +/-20% 130 | 130 | 130 | 140 |
| Minimum +/-20% 20 | 20 | 20 | 20 |
Features of Excavator Screener Crusher Bucket
1. The perfect combination of hydraulic system of excavator and jaw crusher solves the problem that jaw crusher can only work in a fixed location.
2. It is suitable for disposal of urban demolition waste(brick, concrete, stone and other aggregate) realizing- waste ut lization, energy conservation and environmental protection.
3. It meets the construction requirements of smallb construction sites, stone factories etc.
Our Service:
The warranty for our excavator attachments is six months. And, clients could enjoy our on-line consultation and answering service. All our excavator attachments could be customized, OEM is available. As a manufacturer who have strong strong capacity, we usually could arrange delivery for our excavator attachments within 15 days ( delivery can be within one week for cargo that have stock).
If you have any question or want to know more about our excavator attachments,please feel free to send aninquiry to us!We will do the best to help you!
