| Keyword: | Xcavator Attachment Hydraulic Orange Peel Grapple, Lotus Grasping | Application: | Used With Excavator Attachments For Construction Site |
|---|---|---|---|
| Brand: | PA Tech | Type: | JXC04， JXC06，JXC08，JXC10... |
| OEM: | Available | After-sales Service: | Field Installation, Commissioning And Training, Field Installation |
| Video Outgoing-installation: | Available | Machinery Test Report: | Available |
| Warranty: | 6 Months | Suitable For Excavator: | 8-50T |
| Maximum Opening: | 1575-2572mm | ||
| High Light: |
0.6m3 Orange Peel Grapple,1600kg Orange Peel Grapple |
||
Hydraulic Orange Peel Grapple Tools for Waste Materials Recycling field
Description of Lotus grasping, Orange Peel Grapple Multi Grabs
The Orange Peel Grapple is divided into two series: mechanical type and rotary type, which are divided into 4, 5, and 6 parts. According to the requirements of the material to be grabbed, the grab is divided into fully enclosed, semi-closed and open.
Application of Lotus grasping, Orange Peel Grapple Multi Grabs
Orange Peel Grapple is is an effective tool for processing large and irregular materials such as scrap steel, pig iron, ore, and garbage.
Product Features of Lotus grasping, Orange Peel Grapple Multi Grabs
1. Thyssenkrupp XAR400 wear resistance steel is adopted, with light texture and excellent wear resistance.
2. The products of the same grade have the largest grasping force and the widest grasping distance.
3. The high-pressure hose of the cylinder is built-in, and the oil pipeline is completely closed, which protects the hose and prolongs its service life.
4. The cylinder is equipped with a contamination ring, which can effectively prevent tiny impurities in the hydraulic oil from damaging the sealing parts.
Product Parameters of Lotus grasping, Orange Peel Grapple Multi Grabs
| Model | Unit | JX-LZ04 | JX-LZ06 | JX-LZ08 | JX-LZ10 | JX-LZ14 |
| Weight | kg | 550 | 1050 | 1750 | 2150 | 2500 |
| Max. Opening | mm | 1575 | 1866 | 2178 | 2538 | 2572 |
| Open Height | mm | 900 | 1438 | 1496 | 1650 | 1940 |
| Closed Diameter | mm | 600 | 756 | 835 | 970 | 1060 |
| Closed Height | mm | 1150 | 1660 | 1892 | 2085 | 2350 |
| Bucket Capacity | m³ | 0.3 | 0.6 | 0.8 | 1 | 1.3 |
| Max. Load | kg | 800 | 1600 | 2000 | 2600 | 3200 |
| Excavator | ton | 8-11 | 12-17 | 18-25 | 26-35 | 36-50 |
| Flow Demand | l/min | 50 | 90 | 180 | 220 | 280 |
| Opening Times | l/min | 15 | 16 | 15 | 16 | 18 |
